Installation IW17

High performance custom installation in-wall loudspeaker

TROUVER UN REVENDEUR

Installation IW17

High performance custom installation in-wall loudspeaker. High performance architectural audio with Dynaudio sound quality begins here.

The IW17 features the core technologies Dynaudio has become renowned for: A geometrically optimized Magnesium Silicate Polymer (MSP) cone membrane, a specially coated soft dome tweeter and a high quality crossover comprised of select components.

To make the IW 17 both cost effective and easy to install, the frame construction is built of lightweight yet rigid injection-moulded plastic.

The IW 17 is intended for in-wall installations and can be used for almost any high quality stereo, multi-room, or multi-channel audio application.



DYN_IW17_front
DYN_IW17_close_1
DYN_IW17_side2

IW17

Spécifications techniques

  • Status Modèles Discontinués
  • Segment Custom Install
  • Série Legacy
  • Type Enceinte murale
  • Sensibilité (dB @ 2.83V/1m) 88
  • Puissance long terme 100
  • Impédance nominale (Ohm) 4
  • Coupure basse (Hz @ +/- 3 dB) 45
  • Coupure haute (kHz @ +/- 3 dB) 25
  • Crossover 2 voies
  • Tweeter 28 mm soft dome
  • Médium/Woofer 17 cm MSP
Voir plus
DYN_IW17_side2

La série Legacy Install

  • Status :
  • Segment :
  • Série :
  • Type :
  • Sensibilité (dB @ 2.83V/1m) :
  • Puissance long terme :
  • Impédance nominale (Ohm) :
  • Coupure basse (Hz @ +/- 3 dB):
  • Coupure haute (kHz @ +/- 3 dB) :
  • Crossover :
  • Tweeter :
  • Médium/Woofer :
Voir plus
  • IP24
  • Modèles Discontinués
  • Custom Install
  • Legacy
  • Enceinte murale
  • 90
  • 150
  • 4
  • 40
  • 23
  • 2 voies
  • 28 mm soft dome
  • 24 cm MSP
  • IW17
  • Modèles Discontinués
  • Custom Install
  • Legacy
  • Enceinte murale
  • 88
  • 100
  • 4
  • 45
  • 25
  • 2 voies
  • 28 mm soft dome
  • 17 cm MSP
  • IC17
  • Modèles Discontinués
  • Custom Install
  • Legacy
  • Enceinte encastrée
  • 88
  • 100
  • 4
  • 45
  • 25
  • 2 voies
  • 28 mm soft dome
  • 17 cm MSP
  • IP17
  • Modèles Discontinués
  • Custom Install
  • Legacy
  • Enceinte murale
  • 88
  • 150
  • 8
  • 45
  • 23
  • 2 voies
  • 28 mm soft dome
  • 17 cm MSP
